U74LVC17AL-S14-R datasheet(4/6 Pages) UTC

4 / 6 page

U74LVC17A

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R502-410.B

ELECTRICAL CHARACTERISTICS (Ta=25°C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

High-Level Output Voltage

VOH

IOH =-100μAVCC = 1.65~5.5 V

VCC-0.1

IOH =-4mA

VCC =1.65 V

1.20

IOH =-8mA

VCC =2.3 V

1.90

IOH =-16mA

VCC = 3.0 V

2.40

IOH =-24 mA

VCC = 3.0 V

2.30

IOH =-32mA

VCC = 4.5 V

3.80

Low-Level Output Voltage

VOL

IOL =100μA

VCC = 1.65~5.5 V

0.10

IOL =4mA

VCC = 1.65 V

0.45

IOL =8mA

VCC = 2.3 V

0.30

IOL =12mA

VCC = 3.0 V

0.40

IOL =24mA

VCC = 3.0 V

0.55

IOL =32mA

VCC = 4.5 V

0.55

Input Leakage Current

II(LEAK)

VIN =0 to 5.5V, VCC = 0~5.5 V

±5

μA

Power OFF Leakage Current

IOFF

VIN or Vo=5.5V, VCC = 0

±10

μA

Quiescent Supply Current

VIN = VCC or GND, IO =0,

VCC =1.65~5.5 V

μA

Additional Quiescent Supply

Current

ΔIQ

One input at VCC -0.6v,

Other inputs at VCC or GND,

IO =0, VCC =3~5.5 V

500

μA

Input Capacitance

CIN

VO = VCC or GND, VCC = 3.3 V

SWITCHING CHARACTERISTICS (See Test Circuit And Waveforms)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Propagation Delay nA to nY

tPLH / tPHL

VCC=1.8V±0.15V,RL=1KΩ

CL=30pF

3.9

9.3

VCC=2.5V±0.2V,RL=500Ω

1.9

5.7

VCC=3.3V±0.3V,RL=500Ω

CL=50pF

2.2

5.4

VCC=5.0V±0.5V,RL=500Ω

1.5

4.3

OPERATING CHARACTERISTICS (TA=25°С)

PARAMETER

SYMBOL

TEST CONDITIONS

TYP

UNIT

Power Dissipation Capacitance

CPD

f=10MHz

VCC=1.8V

VCC=2.5V

VCC=3.3V

VCC=5V
