TECHNICAL DATA SHEET

TECHNICAL DATA SHEET

2

Cable

Cable Type

PE-SR402FLJ Low PIM

Cable Inner Conductor

Copper, Silver

Cable Outer Conductor

Copper, Tin

Dielectric Type

PTFE

Jacket Material

PVC LSZH

Jacket Diameter

0.163 in [4.14 mm]

Connector 1

Type

N Male

Configuration

Straight

Inner Conductor Material and Plating

Brass, Silver

Coupling Nut Material and Plating

Brass, Tri-Metal

Hex Size

3/4 inch

Body Material and Plating

Brass, Silver

Dielectric Type

PTFE

Connector 2

Type

7/16 DIN Female

Configuration

Straight

Inner Conductor Material and Plating

Beryllium Copper, Silver

Body Material and Plating

Brass, Silver

Dielectric Type

PTFE

RoHS Compliant

Yes

Notes:

• Values at +25 °C, sea level

N Male to 7/16 DIN Female LSZH Jacketed Cable 100 CM Length Using SR402FLJ Low PIM Coax, RoHS from Pasternack

Enterprises has same day shipment for domestic and International orders. Our RF, microwave and millimeter wave products

maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Male to 7/16 DIN Female LSZH Jacketed Cable 100 CM Length Using SR402FLJ Low PIM

Coax, RoHS PE3C2005-100CM

URL:

http://www.pasternack.com/n-male-7-16-female-sr402flj-low-pim-cable-assembly-pe3c2005-100cm-p.aspx

PE3C2005-100CM REV 1.0

PE3C2005-100CM

N Male to 7/16 DIN Female LSZH Jacketed Cable 100 CM

Length Using SR402FLJ Low PIM Coax, RoHS
