Pin settings
ST2149
6/23
Doc ID 15949 Rev 2
1.2
Pin description
Table 2.
Pin description
Pin number
Symbol
Name and function
1I/OVL2
Data input/output
2
OE
Output enable
3I/OVL3
Data input/output
4I/OVL4
Data input/output
5
NC
No connection
6VL
Supply voltage
7VCC
Supply voltage
8
NC
No connection
9
I/OVCC4
Data input/output
10
I/OVCC3
Data input/output
11
GND
Ground
12
I/OVCC2
Data input/output
13
I/OVCC1
Data input/output
14
VCC
Supply voltage
15
VL
Supply voltage
16
I/OVL1
Data input/output
