7 / 25 page ![]() DocID022745 Rev 9 7/25 STBB2 Pin configuration BP B4 Bypass mode selection. When EN is high, connecting this pin to a voltage higher than 1.2 V, the device works in bypass mode. A voltage lower than 0.4 V is required to disable bypass mode. In bypass mode VIN is shorted to VOUT through internal switches. Do not leave this pin floating. VSEL D4 Selection of output voltage for fixed versions (0 VOUT = 2.9 V / 1 VOUT = 3.4 V), (0 VOUT = 3.0 V / 1 VOUT = 3.3 V). This feature is not present in the adjustable version where the VSEL pin must be connected to VINA. Do not leave this pin floating. Table 5. Pin description (continued) Pin name Pin n° Description |
|
