APPLICATION CIRCUITS
PARALLEL APPLICATION
Vcc
GND
TG1
TG2
TG3
TG4
SBT
IRP
OSC
COUT
SP
ROSC
Vcc
GND
TG1
TG2
TG3
TG4
SBT
IRP
OSC
COUT
ROSC
R
LED APPLICATION
Vcc
GND
TG1
TG2
TG3
TG4
SBT
IRP
OSC
COUT
SP
ROSC
OUT2
OUT1
R
Notes:
The following are typical values:
1. B of NPN transistor > 130.
2. SP = 8
W. 1/4W.
3. Piezo buzzer resonant frequency = 1 KHz.
