1. Introduction

The EMPCB.MMCXFSTJ.A.HT connector was designed to be mounted on a PCB edge. The edge

mount configuration allows the connector to be easily slotted onto a PCB board; the maximum

thickness of PCB that the connector can be used with is 0.8mm. The connector pin is directly

soldered onto pads on the PCB. Taoglas connectors are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

DC~6 GHz

Working Voltage

Max. ≤170 Vrms

Dielectric withstanding Voltage

500 Vrms

Insulation Resistance

≥1000M ohms

MECHANICAL

Connector Dimension

7.4mm*4.5 mm

Max. Thickness PCB acceptable

0.8mm

Connector Pin Diameter

0.7mm

Connector Type

MMCX(F) to PCB Edge Mounted

ENVIRONMENTAL

RoHS compliant
