VIPER37
Electrical data
Doc ID 022218 Rev 1
7/35
4.3
Electrical characteristics
(TJ = -25 to 125 °C, VDD = 14 V
(a); unless otherwise specified).
a.
Adjust VDD above VDDon startup threshold before setting to 14 V.
Table 6.
Power section
Symbol
Parameter
Test condition
Min.
Typ.
Max.
Unit
VBVDSS
Breakdown voltage
IDRAIN = 1 mA, VFB = GND
TJ = 25 °C
800
V
IOFF
OFF state drain current
VDRAIN = max. rating,
VFB = GND, TJ = 25 °C
60
µA
RDS(on)
Drain-source on state
resistance
IDRAIN = 0.4 A, VFB = 3 V,
VBR = GND, TJ = 25 °C
4.5
Ω
IDRAIN=0.4 A,VFB=3V,
VBR = GND, TJ = 125 °C
9
Ω
COSS
Effective (energy related)
output capacitance
VDRAIN = 0 to 640 V,
TJ = 25 °C
17
pF
