T-connectors, Covers, Accessories, extended wiring portfolio

XS2

Note: For details on these products, contact your Omron representative

Name

Model

Appearance

Cable connectors with plugs

(open end or connector end)

XS2W Plug connectors (Connector end)

XS2H Plug connectors (Open end)

Connector Assembly Acces-

sories (Crimping, Soldering, or

Screw-on)

XS2F Crimp Tool (for Crimping Connectors)

XS2U Crimping pin (for XS2G/XS2C)

XW4Z Screwdriver (for Screw-on Connectors)

Panel-mounting Connectors

XS2P Sockets (M12)

XS3P Sockets (M8)

XS2M Plugs (M12)

XS3M Plugs (M8)

Flange-mounting Plugs

Screw-mounting Plugs

T-Joints and Y-Joints

Used for branching and for

daisy-chain connections.

XS2R T-Joint/Y-Joint Plug/Socket

Connectors (M12)

XS3R Y-Joint Plug/Socket Connectors

(M8)

T-Joints

Y-Joints

Dust covers

Used to protect unused

connector ports

XS2Z (M12)

XS3Z (M8)

Connector plugs

Connector covers
