4 / 16 page

AD8338

Data Sheet

Rev. 0 | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VBAT to COMM

−0.3 V to +5.5 V

INPR, INPD, INMD, INMR, MODE, GAIN,

FBKM, FBKP, OUTM, OUTP, VAGC,

VREF, OFSN

COMM to VBAT

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 10 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Table 3. Thermal Resistance

Package Type

θJA

Unit

16-Lead LFCSP

48.75

°C/W

ESD CAUTION
