AD633

Data Sheet

Rev. I | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±18 V

Internal Power Dissipation

500 mW

Input Voltages1

±18 V

Output Short-Circuit Duration

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

AD633J

0°C to 70°C

AD633A

−40°C to +85°C

Lead Temperature (Soldering, 60 sec)

300°C

ESD Rating

1000 V

1

For supply voltages less than ±18 V, the absolute maximum input voltage is

equal to the supply voltage.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages.

Table 3.

Package Type

Unit

8-Lead PDIP

90

°C/W

8-Lead SOIC

155

°C/W

ESD CAUTION
