AD736ARZ-R7 datasheet(5/20 Pages) AD

5 / 20 page

Data Sheet

AD736

Rev. I | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±16.5 V

Internal Power Dissipation

200 mW

Input Voltage

Pin 2 through Pin 8

±VS

Pin 1

±12 V

Output Short-Circuit Duration

Indefinite

Differential Input Voltage

+VS and –VS

Storage Temperature Range (Q)

–65°C to +150°C

Storage Temperature Range (N, R)

–65°C to +125°C

Lead Temperature (Soldering, 60 sec)

300°C

ESD Rating

500 V

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

θJA

Unit

8-Lead PDIP

165

°C/W

8-Lead CERDIP

110

°C/W

8-Lead SOIC

155

°C/W

ESD CAUTION
