REV. 0
AD9873
–39–
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm).
100-Lead Metric Quad Flatpack (MQFP)
(S-100C)
0.555 (14.10)
0.551 (14.00)
0.547 (13.90)
81
100
1
50
31
30
51
TOP VIEW
(PINS DOWN)
PIN 1
80
0.742 (18.85) TYP
0.486
(12.35)
TYP
0.015 (0.35)
0.009 (0.25)
0.029 (0.73)
0.023 (0.57)
0.921 (23.4)
0.906 (23.0)
0.685 (17.4)
0.669 (17.0)
0.791 (20.10)
0.787 (20.00)
0.783 (19.90)
0.134
(4.30)
MAX
SEATING
PLANE
0.004
(0.10)
MAX
0.010
(0.25)
MIN
0.041 (1.03)
0.031 (0.78)
0.110 (2.80)
0.102 (2.60)
CONTROLLING DIMENSIONS ARE IN MILLIMETERS
