AMS386 Fiches technique(PDF) 2 Page - Advanced Monolithic Systems Ltd

No de pièce AMS386
Description  Single Supply Operational Amplifiers
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricant  AMS [Advanced Monolithic Systems Ltd]
Site Internet   http://www.ams-semitech.com
Logo AMS - Advanced Monolithic Systems Ltd

AMS386 Fiches technique(HTML) 2 Page - Advanced Monolithic Systems Ltd

  AMS386 Datasheet HTML 1Page - Advanced Monolithic Systems Ltd AMS386 Datasheet HTML 2Page - Advanced Monolithic Systems Ltd
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
SMD Type
IC
Equivalent Schematic and Connection Diagrams
Integrate Circuit
Electrical Characteristics Ta = 25
Parameter
Symbol
Testconditons
Min
Typ
Max
Unit
Operating Supply Voltage
VS
518
V
Quiescent Current
IQ
VS =6V, VIN =0
4
8
mA
Output Power
POUT
VS =16V,RL =32
, THD = 10%
700
1000
mW
VS =6V,f=1kHz
26
10
FfromPin1to8
46
Bandwidth
BW
VS = 6V, Pins 1 and 8 Open
300
KHz
Total Harmonic Distortion
THD
VS =6V, RL =8
,POUT =125 mW,f =1kHz,
Pins 1and8Open
0.2
%
Power Supply Rejection Ratio
PSRR
VS =6V,f=1kHz,CBYPASS =10
F
Pins 1 and 8 Open, Referred to Output
50
dB
Input Resistance
RIN
50
K
Input Bias Current
IBIAS
VS = 6V, Pins 2 and 3 Open
250
nA
AV
Voltage Gain
dB
AMS386
2



Html Pages

1 2
