ADR3540WBRMZ-R7 datasheet(8/20 Pages) AD

8 / 20 page

ADR3525/ADR3530/ADR3533/ADR3540/ADR3550

Data Sheet

Rev. 0 | Page 8 of 20

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 7.

Parameter

Rating

Supply Voltage

6 V

ENABLE to GND SENSE Voltage

VIN

Operating Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature Range

−65°C to +150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 8. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead MSOP (RM-8 Suffix)

132.5

43.9

°C/W

ESD CAUTION
