background image
UNISONIC TECHNOLOGIES CO., LTD
TIP112
NPN SILICON TRANSISTOR
www.unisonic.com.tw
1 of 4
Copyright © 2012 Unisonic Technologies Co., Ltd
QW-R203-022.D
NPN EPITAXIAL SILICON
DARLINGTON TRANSISTOR
DESCRIPTION
The UTC TIP112 is designed for such applications as: DC/DC
converters supply line switching, battery charger, LCD backlighting,
peripheral drivers, Driver in low supply voltage applications (e.g.
lamps and LEDs) and inductive load driver (e.g. relays, buzzers and
motors).
FEATURES
* High DC current gain : hFE = 1000 @ VCE =4V, IC=1A (Min)
* Low collector-emitter saturation voltage
EQUIVALENT TEST (R1≈10kΩ, R2≈0.6kΩ)
R1
R2
E
B
C
ORDERING INFORMATION
Ordering Number
Package
Pin Assignment
Packing
Lead Free
Halogen Free
1
2
3
TIP112L-T60-K
TIP112G-T60-K
TO-126
E
C
B
Bulk
TIP112L-TA3-T
TIP112G-TA3-T
TO-220
B
C
E
Tube
TIP112L-TN3-R
TIP112G-TN3-R
TO-252
B
C
E
Tape Reel
TIP112L-TN3-T
TIP112G-TN3-T
TO-252
B
C
E
Tube
