US2829

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R502-361.b

ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.3 ~ +15

V

Input Voltage

V

Output Voltage

V

Continuous Output Current

±100

mA

Power Dissipation

437

mW

Derated Above 25°C

3.5

mW/°C

Operating Temperature

-40 ~ + 125

°C

Storage Temperature

-65 ~ + 150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

Supply Voltage

4

14

V

Input Voltage

-0.3

V

Operating Temperature

-40

125

°C

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

High-Level Output Voltage

9.75

9.9

V

8

9.1

V

Low-Level Output Voltage

0.18 0.25

V

1

2

V

Positive-going input threshold

voltage

3.3

4

V

6.6

7

V

9.3

10

V

Negative-going input threshold

voltage

1

1.7

V

2

3.3

V

2.5

4.6

V

Input voltage hysteresis

1.3

V

Input Leakage Current

0.2

μA

Supply Current

0.1

15

μA

Input Capacitance

5

10

pF

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Propagation delay from input

(IN) to output(OUT)

40

ns

24

45

ns

50

ns

Output transition time

25

ns

14

30

ns

35

ns
