UNISONIC TECHNOLOGIES CO., LTD

BAT54

DIODE

www.unisonic.com.tw

1 of 3

QW-R601-007,G

SCHOTTKY BARRIER DIODE

DESCRIPTION

Planar Schottky barrier diodes are encapsulated in the SOT-23

small plastic SMD package. Single diodes and dual diodes with

different pin configuration are available.

FEATURES

* Low forward voltage

* Guard ring protected

* Small plastic SMD package

SYMBOL

2

3

1

n.c

ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

3

BAT54L-AE3-R

BAT54G-AE3-R

SOT-23

x

A

K

Tape Reel

Note: Pin Assignment: A: Anode K: Cathode

MARKING
