1 / 6 page

UNISONIC TECHNOLOGIES CO., LTD

U74LVC245

CMOS IC

www.unisonic.com.tw

1 of 6

QW-R502-176.Ba

OCTAL BUS TRANSCEIVER

WITH 3-STATE OUTPUTS

DESCRIPTION

The U74LVC245 is designed for the communication between data

buses asynchronously. While the direction-control(DIR) is high, data

transmits from the A bus to the B bus. Data transmits from the B bus

to the A bus if DIR is low. The output-enable(

OE ) will isolate the

device from the buses when high voltage is applied on it.

FEATURES

* Operate From 1.65V to 3.6V

* Input Accept Voltages to 5.5V

* Partial-Power-Down Mode Operation

ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

Package

Packing

U74LVC245L-D20-T

U74LVC245G-D20-T

DIP-20

Tube

U74LVC245L-P20-R

U74LVC245G-P20-R

TSSOP-20

Tape Reel

U74LVC245L-P20-T

U74LVC245G-P20-T

TSSOP-20

Tube

U74LVC245L-S20-R

U74LVC245G-S20-R

SOP-20

Tape Reel

U74LVC245L-S20-T

U74LVC245G-S20-T

SOP-20

Tube
