HS3JB datasheet(1/2 Pages) TSC

No de pièce	HS3JB

Description	3.0AMPS High Efficient Surface Mount Rectifiers

PDF	2 Pages

Scroll/Zoom	100%

Fabricant	TSC [Taiwan Semiconductor Company, Ltd]

Site Internet	http://www.taiwansemi.com

Logo

1 / 2 page

creat by ART

Glass passivated junction chip.

For surface mounted application

Low forward voltage drop

Low profile package

Fast switching for high efficiency

HS3XB = Specific Device Code

G

= Green Compound

Y

= Year

M

= Work Month

Maximum Ratings and Electrical Characteristics

Rating at 25 ℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%

Symbol

HS

3AB

HS

3BB

HS

3DB

HS

3FB

HS

3GB

HS

3JB

HS

3KB

HS

3MB

Unit

VRRM

50

100

200

300

400

600

800

1000

V

VRMS

35

70

140

210

280

420

560

700

V

VDC

50

100

200

300

400

600

800

1000

V

IF(AV)

A

Trr

nS

Cj

pF

RθjA

OC/W

TJ

OC

TSTG

OC

Features

Weight: 0.093 grams

Typical Thermal Resistance

Type Number

Maximum Average Forward Rectified Current

Polarity: Indicated by cathode band

Typical Junction Capacitance (Note 3)

HS3AB - HS3MB

3.0AMPS High Efficient Surface Mount Rectifiers

Marking Diagram

SMB/DO-214AA

Dimensions in inches and (millimeters)

60

3

Maximum Reverse Recovery Time (Note 2)

Maximum Reverse Current @ Rated VR TA=25 ℃

T A=125 ℃

IR

Note 2: Reverse Recovery Test Conditions: I F=0.5A, IR=1.0A, IRR=0.25A

Operating Temperature Range

Storage Temperature Range

- 55 to + 150

Version:G11

Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.

Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle

80

50

100

A

50

10

250

75

uA

Maximum Instantaneous Forward Voltage (Note 1)

@ 3 A

VF

V

1.0

1.3

1.7

Peak Forward Surge Current, 8.3 ms Single Half Sine-

wave Superimposed on Rated Load (JEDEC method)

Plastic material used carries Underwriters

Laboratory Classification 94V-0

IFSM

Packing: 12mm tape per EIA STD RS-481

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Case: Molded plastic

Mechanical Data

Built-in stain relief, ideal for automatic

placement

Green compound with suffix "G" on packing

code & prefix "G" on datecode

High temperature soldering:

260℃/10 seconds at terminals

Terminal: Pure tin plated, lead free

Pb

RoHS

COMPLIANCE

RoHS

COMPLIANCE
