TL1093

LINEAR INTEGRATED CIRCUIT

NISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R103-045.A

ABSOLUTE MAXIMUM RATINGS (Operating temperature range applies unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Cathode Voltage

VKA

Cathode Current Range(Continuous)

IKA

-100 ~ +150

Reference Input Current Range

IREF

-0.05 ~ +10

Power Dissipation

800

Operating Junction Temperature

+150

°C

Operating Ambient Temperature

TOPR

-40 ~ +85

°C

Storage Temperature

TSTG

-65 ~ +150

°C

Note:

Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

MIN TYP MAX UNIT

Cathode Voltage

VKA

VREF

Cathode Current

IKA

100

ELECTRICAL CHARACTERISTICS (TC= 25°C, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reference Input Voltage

VREF

VKA=VREF,IKA=10mA

2.470 2.495 2.520

Deviation of reference Input Voltage Over

temperature

ΔT

ΔVREF VKA=VREF,IKA=10mA

°C≤Ta≤70°C

4.5

ΔVKA=10V~VREF

-1.0

-2.7 mV/V

Ratio of Change in Reference Input

Voltage to the Change in Cathode Voltage

REF

ΔV

IKA=10mA

ΔVKA=36V~10V

-0.5

-2.0 mV/V

Reference Input Current

IREF

IKA=10mA, R1=10kΩ, R2=∞

1.5

µA

Deviation of Reference Input Current Over

Full Temperature Range

ΔT

ΔIREF

IKA=10mA, R1=10kΩ, R2=∞

Ta =full Temperature

0.4

1.2

µA

Minimum Cathode Current for Regulation

IKA(MIN) VKA=VREF

0.19

0.5

Off-State Cathode Current

IKA(OFF) VKA=36V, VREF=0

0.05

1.0

µA

Dynamic Impedance

ZKA

VKA=VREF, IKA=1 to 100mA

f≤1.0kHz

0.15

0.5

Ω
