AP2161/AP2171

1A SINGLE CHANNEL CURRENT-LIMITED POWER

SWITCH

AP2161/AP2171 Rev. 6

4 of 19

JUNE 2009

DS31564

www.diodes.com

Absolute Maximum Ratings

Symbol

Parameter

Ratings

Units

ESD HBM

Human Body Model ESD Protection

ESD MM

Machine Model ESD Protection

for MSOP-8L-EP, SOT25 packages

400

Machine Model ESD Protection

for DFN2018-6, SOP-8L packages

300

VIN

Input Voltage

6.5

VOUT

Output Voltage

VIN + 0.3

VEN , VFLG

Enable Voltage

6.5

Iload

Maximum Continuous Load Current

Internal Limited

TJmax

Maximum Junction Temperature

150

°C

TST

Storage Temperature Range (Note 3)

-65 to 150

°C

Notes:

3. UL Recognized Rating from -30°C to 70°C (Diodes qualified

TST from -65°C to 150°C)

Recommended Operating Conditions

Symbol

Parameter

Min

Max

Units

VIN

Input voltage

2.7

5.5

IOUT

Output Current

1.0

Operating Ambient Temperature

-40

°C
