BAS3007A-RPP datasheet(2/6 Pages) INFINEON

No de pièce	BAS3007A-RPP

Description	Low VF Schottky Diode Array

PDF	6 Pages

Scroll/Zoom	100%

Fabricant	INFINEON [Infineon Technologies AG]

Site Internet	http://www.infineon.com

Logo

2 / 6 page

2007-11-20

BAS3007A...

Thermal Resistance

Parameter

Symbol

Value

Unit

Junction - soldering point1)

RthJS

≤ 95

K/W

Electrical Characteristics at TA = 25°C, unless otherwise specified

Parameter

Symbol

Values

Unit

min.

typ.

max.

DC Characteristics

Reverse current (per diode)2)

VR = 12 V

VR = 30 V

350

µA

Forward voltage (per diode)2)3)

IF = 100 mA

IF = 350 mA

IF = 500 mA

IF = 700 mA

IF = 900 mA

0.35

0.4

0.45

0.5

0.6

0.4

0.5

0.55

0.6

0.7

AC Characteristics

Diode capacitance (per diode)

VR = 5 V, f = 1 MHz

1For calculation of RthJA please refer to Application Note Thermal Resistance

2Pulsed test, tp = 300 µs; D = 0.01

3When used as shown for Reverse Polarity Protection (RPP, see page 4), the voltage available to the circuit

being protected will be two diode drops below the power supply voltage. In other words, the supply current

will pass through two diodes.
