ADV3221/ADV3222
Rev. 0 | Page 4 of 20
ADV3221
ADV3222
Parameter
Test Conditions/Comments
Min
Typ
Max
Min
Typ
Max
Unit
POWER SUPPLIES
Supply Current
V+, output enabled, no load
7
8
7.5
9
mA
V+, output disabled (CS high)
1.6
2.0
1.8
2.2
mA
V−, output enabled, no load
7
8
7.5
9
mA
V−, output disabled (CS high)
1.6
2.0
1.8
2.2
mA
Supply Voltage Range
±4.5
±5.5
±4.5
±5.5
V
Power Supply Rejection (PSR)
f = 100 kHz
−70
−65
dB
f = 1 MHz
−60
−55
dB
TEMPERATURE
Operating Temperature Range
Still air
−40
+85
−40
+85
°C
Junction-to-Ambient Thermal Impedance (θJA)
Operating (still air)
81
81
°C/W
TIMING AND LOGIC CHARACTERISTICS
Table 2.
Parameter
Symbol
Min
Typ
Max
Unit
A0, A1, CS Setup Time
t1
20
ns
CK1 Pulse Width
t2
40
ns
CK1 to CK2 Pulse Separation
t3
40
ns
CK2 Pulse Width
t4
40
ns
A0, A1, CS Hold Time
t5
20
ns
Table 3. Logic Levels
VIH
VIL
IIH
IIL
IIH
IIL
A0, A1, CK1, CK2, CS
A0, A1, CK1, CK2, CS
A0, A1, CS
A0, A1, CS
CK1, CK2
CK1, CK2
+2.0 V min
+0.8 V max
±2 μA max
±2 μA max
+60 μA max
+10 μA max
