STTS2002

Temperature sensor registers

Doc ID 17216 Rev 1

5/9

2

Temperature sensor registers

The temperature sensor component is comprised of various user-programmable registers.

These registers are required to write their corresponding addresses to the pointer register.

They can be accessed by writing to their respective addresses (see Table 2). Pointer

register bits 7 - 4 must always be written to '0'. This must be maintained, as not setting these

bits to '0' may keep the device from performing to specifications.

The main registers include the :

●

Capability register (read-only)

●

Configuration register (read/write)

●

Temperature register (read-only)

●

Temperature trip point registers (read/write), including

–

Alarm temperature upper boundary

–

Alarm temperature lower boundary and

–

Critical temperature

●

Manufacturer’s ID register (read-only)

●

Device ID and device revision ID register (read-only)

●

Temperature resolution register (TRES) (read/write)

Table 2.

Temperature sensor registers summary

Address (hex)

Register name

Power-on default

Not applicable

Address pointer

Undefined

00

Capability

B-grade

0x006F

01

Configuration

0x0000

02

Alarm temperature upper boundary trip

0x0000

03

Alarm temperature lower boundary trip

0x0000

04

Critical temperature trip

0x0000

05

Temperature

Undefined

06

Manufacturer’s ID

0x104A

07

Device ID/revision

0x0300

08

Temperature resolution register

0x0001
