FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Mid-Band

m

Total

Range

Max.

L

M

U

L

M

U

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ.

10-1000

DC-800

7.0

0.10

70 55

60 43

47 37

45 32

35 25

26 17

16

L = low range [f

M = mid range [10 f

U = upper range [f

m= mid band [2f

1 dB COMP.: +5 dBm typ.

†

Conversion loss increases 0.5 when IF is above150 MHz

ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

Level 10 (LO Power +10 dBm) 10 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Outline Drawing

Electrical Specifications

REV. OR

M109914

ADEX-R10LH+

ED-12873/5

WL/TD/QL

070516

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 7.0 dB typ.

• excellent L-R isolation, 60 dB typ.

• good VSWR, 1:8:1 typ. for LO,

1.5:1 typ. for RF, 1.5:1 typ. for IF

• good performance to 1500 MHz

• low profile package

• aqueous washable

• protected by US Patent 6,133,525 and 6,947,717

Applications

• cellular

• instrumentation

• VHF/UHF receivers

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

ADEX-R10LH+

CASE STYLE: CD542

PRICE: $3.35 ea. QTY. (10-49)

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.

10.10

40.10

6.40

70.41

63.96

1.40

1.53

70.10

100.10

7.05

71.47

48.53

1.41

1.51

130.10

160.10

7.08

67.22

44.08

1.42

1.52

190.10

220.10

6.89

66.26

42.14

1.42

1.50

250.10

280.10

7.03

65.92

42.34

1.44

1.52

310.10

340.10

6.97

64.97

41.47

1.46

1.55

370.10

400.10

7.00

61.87

40.62

1.49

1.57

430.10

460.10

6.96

60.97

38.57

1.51

1.60

490.10

520.10

7.00

62.56

37.21

1.53

1.65

550.10

580.10

7.16

56.40

35.22

1.56

1.69

610.10

640.10

7.09

52.53

33.19

1.55

1.72

670.10

700.10

6.94

55.81

31.14

1.54

1.74

730.10

760.10

7.16

77.09

30.24

1.58

1.81

790.10

820.10

7.30

57.93

30.30

1.61

1.86

850.10

880.10

7.52

52.89

30.93

1.64

1.89

910.10

940.10

7.81

50.96

30.99

1.65

1.92

970.10

1000.10

7.81

55.37

29.61

1.62

1.94

1030.10

1060.10

7.66

61.99

27.44

1.54

1.96

1090.10

1120.10

7.44

62.69

25.31

1.43

1.99

1150.10

1180.10

7.17

51.89

23.66

1.32

2.06
