3-001-R-11 datasheet(1/1 Pages) ALTECH

No de pièce	3-001-R-11

Description	22 mm Thermoplastic Enclosures White/Black Operator Capacity 2

PDF	1 Pages

Scroll/Zoom	100%

Fabricant	ALTECH [Altech corporation]

Site Internet	http://www.altechcorp.com

Logo

1 / 1 page

Isometric View

1:2

R

This Drawing is the property of

35 Royal Road

Flemington, NJ 08822-6000

(908) 806-9400

Fax (908) 806-9490

and is a confidential

disclosurelent without

consideration other than the

borrower’s agreement that it

shall not be reproduced,

copied, lent or disposed of

directly or indirectly nor

used for any purpose other

than that for which it is

specifically furnished.

unless otherwise specified:

all dimensions are in millimeters

third angle projection

M

E

T

R

I

C

tolerance

XX

XX.X

XX.XX

ALL

±1 mm

±0.5 mm

±0.2 mm

− mm

=

titel

drawn by:

checked by:

released by:

drawing no.:

rev.:

scale:

sheet:

of:

Laszlo Gyorgypal

11/2/2007

Philipp Ernstberger

11/2/2007

22 mm Thermoplastic Enclosures White/Black Operator Capacity 2

3-001-R-11

1PB-3-001-R-11

-

1

Laszlo Gyorgypal

revision for dwg # 1PB-3-001-R-11

rev

-

ch.no.

-

description

original design

date

revised by

11/2/2007

Philipp E.

103.57 mm

[4.1 in]

50.60 mm

[2.0 in]

R11.20 mm

[.4 in]

2x

PG 13.5 or M20

Plastic enclosure suited for

non-illuminated push buttons with

maximum 2 contact elements.
