SSM2335
Rev. 0 | Page 11 of 1
6
TYPICAL APPLICATION CIRCUITS
SHUTDOWN
0.1µF
VDD
POP-AND-CLICK
SUPPRESSION
OUT–
OUT+
IN+
VBATT
2.5V TO 5.5V
IN–
MODULATOR
(Σ-Δ)
GND
10µF
47nF*
47nF*
EXTERNAL GAIN SETTINGS = 160kΩ/(20kΩ + REXT)
*INPUT CAPACITORS ARE OPTIONAL IF INPUT DC COMMON-MODE
VOLTAGE IS APPROXIMATELY VDD/2.
SD
AUDIO IN–
AUDIO IN+
SSM2335
20kΩ
160kΩ
160kΩ
20kΩ
REXT
REXT
FET
DRIVER
BIAS
INTERNAL
OSCILLATOR
Figure 31. Differential Input Configuration, User-Adjustable Gain
SHUTDOWN
0.1µF
VDD
POP-AND-CLICK
SUPPRESSION
OUT–
OUT+
VBATT
2.5V TO 5.5V
MODULATOR
(Σ-Δ)
GND
10µF
47nF
47nF
SD
SSM2335
20kΩ
160kΩ
160kΩ
20kΩ
REXT
REXT
FET
DRIVER
BIAS
INTERNAL
OSCILLATOR
EXTERNAL GAIN SETTINGS = 160kΩ/(20kΩ + REXT)
IN+
IN–
AUDIO IN+
Figure 32. Single-Ended Input Configuration, User-Adjustable Gain
