ADA4075-2
Rev. 0 | Page 11 of 24
INPUT
OUTPUT
VSY = ±15V
–10mV
+10mV
0V
TIME (2µs/DIV)
ERROR BAND
Figure 38. Negative Settling Time to 0.01%
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±15V
Figure 39. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0
VSY = ±15V
RS1
RS2
Figure 40. Current Noise Density
INPUT
OUTPUT
VSY = ±5V
–6mV
+6mV
0V
TIME (2µs/DIV)
ERROR BAND
Figure 41. Negative Settling Time to 0.01%
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±5V
Figure 42. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0
VSY = ±5V
RS1
RS2
Figure 43. Current Noise Density
