Section 8 User Break Controller (UBC)
Rev. 2.00 Sep. 24, 2008 Page 179 of 1468
REJ09B0412-0200
8.4.3
Condition Match Flag
Condition match flags are set when the break conditions match. The condition match flags of the
UBC are listed in table 8.2.
Table 8.2
List of Condition Match Flags
Register
Flag Bit
Source
BRCRA
CMFCPA (bit 13)
Indicates that the condition matches in the CPU cycle
for channel A
BRCRB
CMFCPB (bit 13)
Indicates that the condition matches in the CPU cycle
for channel B
BRCRC
CMFCPC (bit 13)
Indicates that the condition matches in the CPU cycle
for channel C
BRCRD
CMFCPD (bit 13)
Indicates that the condition matches in the CPU cycle
for channel D
