background image
Section 7 Interrupt Controller
Rev. 2.00 Sep. 24, 2008 Page 162 of 1468
REJ09B0412-0200
Table 7.5
Number of Execution States in Interrupt Handling Routine
Object of Access
External Device
8-Bit Bus
16-Bit Bus
Symbol
On-Chip
Memory
2-State
Access
3-State
Access
2-State
Access
3-State
Access
Vector fetch S
h
1
8
12 + 4m
4
6 + 2m
Instruction fetch S
I
1
4
6 + 2m
2
3 + m
Stack manipulation S
K
1
8
12 + 4m
4
6 + 2m
[Legend]
m:
Number of wait cycles in an external device access.
7.6.5
DTC and DMAC Activation by Interrupt
The DTC and DMAC can be activated by an interrupt. In this case, the following options are
available:
• Interrupt request to the CPU
• Activation request to the DTC
• Activation request to the DMAC
• Combination of the above
For details on interrupt requests that can be used to activate the DTC and DMAC, see table 7.2,
section 10, DMA Controller (DMAC), and section 12, Data Transfer Controller (DTC).
