Section 7 Interrupt Controller
Rev. 2.00 Sep. 24, 2008 Page 131 of 1468
REJ09B0412-0200
7.2
Input/Output Pins
Table 7.1 shows the pin configuration of the interrupt controller.
Table 7.1
Pin Configuration
Name
I/O
Function
NMI
Input
Nonmaskable External Interrupt
Rising or falling edge can be selected.
IRQ11 to IRQ0
Input
Maskable External Interrupts
Rising, falling, or both edges, or level sensing, can be
independently selected.
7.3
Register Descriptions
The interrupt controller has the following registers.
• Interrupt control register (INTCR)
• CPU priority control register (CPUPCR)
• Interrupt priority registers A to O, Q, and R
(IPRA to IPRO, IPRQ, and IPRR)
• IRQ enable register (IER)
• IRQ sense control registers H and L (ISCRH, ISCRL)
• IRQ status register (ISR)
• Software standby release IRQ enable register (SSIER)
