Maximum rating

13/33

Maximum rating

Stressing the device above the rating listed in the “Absolute maximum ratings” table may

cause permanent damage to the device. These are stress ratings only and operation of the

device at these or any other conditions above those indicated in the operating sections of

this specification is not implied. Exposure to absolute maximum rating conditions for

extended periods may affect device reliability. Refer also to the STMicroelectronics SURE

program and other relevant quality documents.

4.1

Thermal data

Table 4.

Absolute maximum ratings (all voltages are referenced to GND)

Symbol

Parameters

Values

Unit

VCC

Supply voltage to ground

-0.5 to +7.0

Logic input voltage

-0.5 to VCC+0.5

Power dissipation (1)

De-rate at -9.6 mW/°C at TA = 25°C or higher

1200

Operating ambient temperature

-40 to 85

°C

Junction temperature

150

°C

TSTG

Storage temperature

-65 to +150

°C

Lead temperature (10 sec)

300

°C

VESD

Electrostatic discharge voltage on all pins (2)

Human body model

In accordance with the JEDEC standard

-4 to +4

Table 5.

Thermal data

Symbol

Parameter

Min

Typ

Max

Unit

TthJC

Thermal resistance junction-ambient

°C/W
