ST52T430/E430
76/88
12.7.2 Multi-supply Configuration.
When several types of ground (VSS, VSSA,...) and
power supply (VDD, VDDA,...) are available for any
reason (better noise immunity...), the structure
illustrated in Figure 12.10 is implemented in order
to protect the device against ESD.
Figure 12.10 ESD Protection for Multisupply Configuration
VSSA
VDDA
VDDA
VDD
VSS
(4)
(4)
BACK TOBACKDIODE
BETWEEN GROUNDS
