ADL5385ACPZ-R7 Fiches technique(PDF) 5 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5385ACPZ-R7 Fiches technique(HTML) 5 Page - Analog Devices |
|
|
5 / 24 page  Data Sheet ADL5385 Rev. D | Page 5 of 24 Parameter Test Conditions/Comments Min Typ Max Unit Noise Floor 20 MHz offset from LO, all BB inputs at a bias of 500 mV −159 dBm/Hz 20 MHz offset from LO, output power = −5 dBm −157 dBm/Hz Output Return Loss −19 dB OUTPUT FREQUENCY = 1450 MHz Output Power Single (lower) sideband output 4.4 dBm Output P1 dB 10 dBm Carrier Feedthrough Unadjusted (nominal drive level) −36 dBm +85°C after optimization at +25°C −50 dBm −40°C after optimization at +25°C −50 dBm Sideband Suppression Unadjusted (nominal drive level) −44 dBc +85°C after optimization at +25°C −61 dBc −40°C after optimization at +25°C −51 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 4 dBm −64 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 4 dBm −52 dBc Output IP2 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 63 dBm Output IP3 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 24 dBm Quadrature Phase Error 0.42 Degrees I/Q Amplitude Balance −0.02 dB Noise Floor 20 MHz offset from LO, all BB inputs at a bias of 500 mV −160 dBm/Hz Output Return Loss −33 dB OUTPUT FREQUENCY = 1900 MHz Output Power Single (lower) sideband output 3.4 dBm Output P1 dB 9 dBm Carrier Feedthrough Unadjusted (nominal drive level) −35 dBm +85°C after optimization at +25°C −51 dBm −40°C after optimization at +25°C −51 dBm Sideband Suppression Unadjusted (nominal drive level) −33 dBc +85°C after optimization at +25°C −43 dBc −40°C after optimization at +25°C −47 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 3 dBm −58 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 3 dBm −47 dBc Output IP2 F1 = +3.5 MHz, F2 = +4.5 MHz, POUT = −3 dBm per tone 57 dBm Output IP3 F1 = +3.5 MHz, F2 = +4.5 MHz, POUT = −3 dBm per tone 22 dBm Quadrature Phase Error 2.6 Degrees I/Q Amplitude Balance 0.003 dB Noise Floor 20 MHz offset from LO, all BB inputs at a bias of 500 mV −160 dBm/Hz 20 MHz offset from LO, output power = −5 dBm −156 dBm/Hz Output Return Loss −20 dB OUTPUT FREQUENCY = 2150 MHz Output Power Single (lower) sideband output 2.6 dBm Output P1 dB 8 dBm Carrier Feedthrough Unadjusted (nominal drive level) −36 dBm +85°C after optimization at +25°C −47 dBm −40°C after optimization at +25°C −48 dBm Sideband Suppression Unadjusted (nominal drive level) −37 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 2.6 dBm −56 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 2.6 dBm −45 dBc Output IP2 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 54 dBm Output IP3 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 21 dBm Quadrature Phase Error 1.5 Degrees I/Q Amplitude Balance <0.05 dB |
|
