Model: HG914Y

Specifications

Electrical Specifications

Frequency

900 - 928 MHz

Gain

14 dBi

-3 dB Beam Width

30 degrees

Front to Back Ratio

15 dB

Impedance

50 Ohm

Max. Input Power

50 Watts

VSWR

< 1.5:1 avg.

Lightning Protection

DC Short

Mechanical Specifications

Weight

< 4 lbs. (1.8 Kg)

Length

43 in.(109 cm)

Material

Extruded Aluminum

Finish Material

White UV Polymer

Mounting

2 3/8" dia. mast max.

Polarization

Vertical or Horizontal

Operating Temperature

-40° C to 85° C

(-40° F to 185° F)

Wind Survival

>150 MPH

RF Antenna Gain Patterns
