 45 / 56 page
background image
www.geehy.com
Page 44
7.
Packaging Information
Figure 18 Tape Dimensions
A0
Dimension designed to accommodate the component width
B0
Dimension designed to accommodate the component length
K0
Dimension designed to accommodate the component thickness
P1
Dimension designed to accommodate the component pitch
W
Overall width of the carrier tape
Figure 19 Quadrant allocation in PIN1 direction in tape
Figure 20 Reel Dimensions
