background image
EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet
OPTO INTERRUPTER ITR
Everlight Electronics Co., Ltd.
http:\\www.everlight.com
Rev 2
Page: 1 of 8
Device No：CDRX-990-007
Prepared date：2007/4/8
Prepared by：zhouhong
ITR9904
█ Features
․Fast response time
․High analytic
․Cut-off visible wavelength λp=940nm
․High sensitivity
․This product itself will remain within RoHS compliant version.
█ Descriptions
The ITR9904 consists of an infrared emitting diode
and an NPN silicon phototransistor, encased oblique angle
(45°) on converging optical axis in a black Thermo-plastic
housing. The phototransistor receives radiation from the
IRED only, and avoids the noise from ambient light.
█ Applications
․Copier
․Scanner
․Non-contact Switching
․For Direct PC Board
█ Device Selection Guide
Device No.
Chip Material
LENS COLOR
IR1254-R8
GaAs
Blue
PT1254-6B
Silicon
Black
