Solenoid coil

VACF-B-R8-1RAL

Part number: 8150878

General operating condition

Data sheet

Feature

Value

Actuation type

Electrical

Mounting position

Any

Conforms to standard

ISO 20401

Impact energy value

IK06

Signal status display

LED

Duty cycle

100%

Insulation class

H

Enameled wire insulation class

H

Nominal pick-up current per solenoid coil

138 mA to 70 ms

Nominal current with current reduction

50 mA after 70 ms

Coil characteristics

24VDC:NS1,2:HS3.3

Permissible voltage fluctuations

+/- 10 %

Certification

c UL us - Recognized (OL)

CE marking (see declaration of conformity)

As per EU EMC directive

As per EU RoHS directive

UKCA marking (see declaration of conformity)

To UK instructions for EMC

To UK RoHS instructions

Certificate issuing authority

UL MH18122

Corrosion resistance class (CRC)

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Temperature of medium

-20 °C ... 60 °C

Degree of protection

IP65

Ambient temperature

-20 °C ... 60 °C

Product weight

49 g

Max. cable length

30 m

Electrical connection 1, connection type

Plug

Electrical connection 1, connection technology

M8x1 A-coded as per EN 61076-2-104

Electrical connection 1, number of pins/wires

3

Electrical connection for input 1, connection pattern

00991974

Electrical connection 1, type of mounting

Screw-type lock

Type of mounting

With knurled nut

Note on materials

RoHS-compliant

Housing material

PA

Steel

Solenoid coil material

Copper

Steel

Thermoplastic

4/29/26 - Subject to change - Festo SE & Co. KG

1/2
