TIA/EIA-606-A

Labeling Compliance

TIA/EIA-606-A Standard

For compliance with the TIA/EIA-606-A standard, Panduit has the solution.

This brochure will walk you through the labeling requirements of the standard and

introduce you to identification solutions specifically designed to comply with

TIA/EIA-606-A. The standard establishes guidelines for owners, end users,

manufacturers, consultants, contractors, designers, installers and facility

administrators involved in the administration of the telecommunications

infrastructure. Proper identification of your network allows moves, adds, changes,

trouble shooting and repairs to be accomplished faster and more efficiently.

The Ultimate ID ® Network Labeling System

The Ultimate ID ® Network Labeling System featured in this brochure was designed

specifically with the TIA/EIA-606-A standard in mind. It includes faceplates, surface

mount boxes, patch panels, marker ties, labels for desktop printers and the

PanTher ™ LS8E Hand-Held Thermal Transfer Printer. All Ultimate ID ® hardware

uses labels with a common compact height. This not only enhances the

appearance of the installation, but also saves time and money by providing a clear

and efficient way to label according to the TIA/EIA-606-A standard. All labels are

positioned adjacent to, centered and parallel to the module they are identifying. The

appearance of the installation can be further enhanced by using a consistent font

size throughout the installation. The PanTher™ LS8E Printer and Panduit desktop

labeling software can both be used to mechanically print labels with the same font.

For detailed information on related Panduit identification products, you may

request the following information from our customer service representatives or by

downloading from the Panduit web site:

• Panduit Physical Infrastructure Systems Catalog

• PanTher™ LS8E Hand-Held Thermal Transfer Printer: Product Bulletin

• TDP43MY Thermal Transfer Printer: Product Bulletin

• Easy-Mark ™ Labeling Software: Product Bulletin

Products that are a part of the

Ultimate ID ® Network Labeling

System are identified with this icon.
