Clock Circuitry

The card clock signal (CLK) is derived from a clock sig-

nal input to XTAL1 or from a crystal operating at up to

20MHz connected between XTAL1 and XTAL2. The

output clock frequency of CLK is selectable through

inputs CLKDIV1 and CLKDIV2. The CLK signal fre-

Table 1 for the frequency generated on the CLK signal

given the inputs to CLKDIV1 and CLKDIV2.

Note that CLKDIV1 and CLKDIV2 must not be changed

simultaneously; a delay of 10ns minimum between

changes is needed. The minimum duration of any state

of CLK is eight periods of XTAL1.

The frequency change is synchronous: during a transi-

tion of the clock divider, no pulse is shorter than 45% of

the smallest period, and the first and last clock pulses

about the instant of change have the correct width.

When changing the frequency dynamically, the change

is effective for only eight periods of XTAL1 after the

command.

XTAL1. To reach a 45% to 55% duty factor on CLK,

XTAL1 should have a 48% to 52% duty factor with tran-

sition times less than 5% of the period.

With a crystal, the duty factor on CLK can be 45% to

55% depending on the circuit layout and on the crystal

characteristics and frequency. In other cases, the duty

factor on CLK is guaranteed between 45% and 55% of

the clock period.

If the crystal oscillator is used or if the clock pulse on

XTAL1 is permanent, the clock pulse is applied to the

card as shown in the activation sequences in Figures 3

and 4. If the signal applied to XTAL1 is controlled by

the host microcontroller, the clock pulse is applied to

the card when it is sent by the system microcontroller

(after completion of the activation sequence).

I/O Transceivers

The three data lines I/O, AUX1, and AUX2 are identical.

This section describes the characteristics of I/O and

I/OIN but also applies to AUX1, AUX1IN, AUX2, and

AUX2IN.

I/O and I/OIN are pulled high with an 11k

Ω resistor (I/O

to VCC and I/OIN to VDD) in the inactive state. The first

side of the transceiver to receive a falling edge

becomes the master. When a falling edge is detected

(and the master is decided), the detection of falling

edges on the line of the other side is disabled; that side

transistor on the slave side is turned on, thus transmit-

ting the logic 0 present on the master side.

When the master side asserts a logic 1, a p transistor

and then both sides return to their inactive (pulled up)

states. This active pullup provides fast low-to-high tran-

depends only on the internal pullup resistor and the

load current. Current to and from the card I/O lines is

limited internally to 15mA. The maximum frequency on

these lines is 1MHz.

Inactive Mode

The DS8113 powers up with the card interface in the

inactive mode. Minimal circuitry is active while waiting

for the host to initiate a smart card session.

•

All card contacts are inactive (approximately 200

Ω

to GND).

•

Pins I/OIN, AUX1IN, and AUX2IN are in the high-

impedance state (11k

Ω pullup resistor to VDD).

•

Voltage generators are stopped.

•

XTAL oscillator is running (if included in the device).

•

Voltage supervisor is active.

•

The internal oscillator is running at its low frequency.

Activation Sequence

After power-on and the reset delay, the host microcon-

troller can monitor card presence with signals OFF and

CMDVCC, as shown in Table 2.

Smart Card Interface

_______________________________________________________________________________________

9

Table 1. Clock Frequency Selection

CLKDIV1

CLKDIV2

0

0

0

1

1

1

1

0

Table 2. Card Presence Indication

OFF

CMDVCC

STATUS

High

High

Card present.

Low

High

Card not present.
