background image
ADL5382
Rev. 0 | Page 11 of 28
DISTRIBUTIONS FOR fRF = 1900 MHz
28
29
30
31
32
33
0
20
40
60
80
100
INPUT IP3 (dBm)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 27. IIP3 Distributions, fRF = 1900 MHz
12
13
14
15
16
17
0
20
40
60
80
100
INPUT P1dB (dBm)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 28. IP1dB Distributions, fRF = 1900 MHz
–0.2
–0.1
0
0.1
0.2
0
20
40
60
80
100
GAIN MISMATCH (dB)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 29. IQ Gain Mismatch Distributions, fRF = 1900 MHz
45
50
55
60
65
70
75
80
85
0
20
40
60
80
100
INPUT IP2 (dBm)
TA = –40°C
TA = +25°C
TA = +85°C
I CHANNEL
Q CHANNEL
Figure 30. IIP2 Distributions for I Channel and Q Channel, fRF = 1900 MHz
14.0
14.5
15.0
15.5
16.0
16.5
17.0
0
20
40
60
80
100
NOISE FIGURE (dB)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 31. Noise Figure Distributions, fRF = 1900 MHz
–1.00
–0.75
–0.50
–0.25
0
0.25
0.50
0.75
1.00
0
20
40
60
80
100
QUADRATURE PHASE ERROR (Degrees)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 32. IQ Quadrature Phase Error Distributions, fRF = 1900 MHz
