DESCRIPTION

Two small moulded case current transformers

suitable for primary currents from 1A to 500A

using cable or bar primaries

APPLICATION

For use where space is limited within the panel,

and where a built in choice of fixing methods is

required.

15 SERIES MOULDED CASE

CURRENT TRANSFORMERS

FEATURES

• Three built in fixing methods

- Base, Din Rail & Busbar mounting

• Built in hinged terminal cover

• Terminals suitable for screw or push on

connectors

• Small size enables mounting where busbars

run close together

• Case moulded in high impact polyester

• Secondary terminals with double layout

• Primary ranges from 1A to 500A

TECHNICAL OVERVIEW

• Conforms to IEC 44-1 / IEC 185, BS 7626

• Insulation level 0.72/3kV

• Ambient temperature range -20º to 70ºc

• Self extinguishing to UL94VO

• Enclosure to IP20

• CE approved

• Manufactured to ISO 9002

DIN rail mounting

Base mounting

Hinged terminal cover

Busbar mounting
