1 / 41 page  IP5389 V1.22 www.injoinic.com 1 / 41 Copyright © 2022, Injoinic Corp. A Power Bank SOC With Integrated Buck-Boost Driver Supporting Bi-directional Fast Charging Protocol Such As SCP, VOOC, PD3.0, Supporting 2~5 Series Batteries and Supporting Maximum Power 100W 1 Feature Supporting Multiple USB Ports Simultaneously 2 USB A output ports 1 USB C input/output port 1 USB B input port or Lightning input port or C input/output port Fast Charging Every port supports fast charging Support QC2.0/QC3.0/QC3+ output Support FCP input/output Support AFC input/output Support SCP input/output Support VOOC input/output Support DRP try.SRC, PD3.0 input/output Support BC1.2,Apple Integrated USB PD2.0/PD3.0 Protocol Support PD2.0 input/output protocol Support PD3.0 input/output and PPS output protocol Support 5V/9V/12V/15V/20V input Support 5V/9V/12V/15V/20V output Support adjustable voltage in 20mV increments in PPS Mode Integrate hardware Bi-phase mark codec (BMC) protocol Integrate Physical Layer protocol Integrate hardware CRC Support Hard Reset Integrates recognition and support of emark cable Power Control Integrated bidirectional BUCK-BOOST NMOS driver Integrated charge-pump to control external NMOS Charge Adaptive charging current adjustment Support 3.65V/4.15V/4.2V/4.3V/4.35V/4.4V battery Support 2/3/4/5 batteries in series Support charging Lithium Iron Phosphate Battery（3.65V） Boost Maximum output power 100W Up to 97%@5V/2A efficiency with synchronous switching Support line compensation Battery Level Display Integrated 14-bit ADC and coulombmeter Support 4 LEDs to indicate battery level Support 88/188 nixie tube Support choosing nixie tube or LED for battery level indicator by external pin Self-learning coulombmeter, more uniform power display Support configuring initial battery capacity by external pin Other Functions Automatic detection of mobile phone plugging and unplugging Fast charging status indication Battery temperature detection Enter standby mode automatically in light load Support multiple key mode selections Integrated lighting driver Multiple Protections,High Reliability Input overvoltage and undervoltage protection Output overcurrent, overvoltage, short circuit protection Battery overcharge, overdischarge, overcurrent protection Overtemperature protection NTC protection for charging and discharging battery ESD 4kV, input (including CC/DP/DM pins) withstand voltage 30V Low BOM Cost Integrated switch power MOSFET driver Single inductor for charging and discharging Package Size：8mm × 8mm 0.4pitch QFN64 2 Description IP5389 is a power management SOC that integrates QC2.0 / QC3.0 / QC3+ output fast charging protocol, AFC/FCP/SCP/ VOOC input and output fast charging protocol, USB C PD2.0/PD3.0 input and output fast charging protocol and PPS output protocol, BC1.2/iPhone protocol, synchronous bi-directional buck-boost |
