C＜3%

1.0Hz Flash

OFF

2 LED mode 2 display：

During charging: D1 LED flash on cycle of 2s (1s on and 1s off), when fully charged, constantly on;

During discharging: D2 LED is constantly on, when voltage lower than 3.2V, flash on cycle of 1s (0.5s on and 0.5s

off), when voltage is lower than 3.0V, system is power down.

1 LED mode 1 display:

During charging: LED flash on cycle of 2s (1s on and 1s off), when fully charged, constantly on;

During discharging: LED is constantly on, when voltage lower than 3.2V, flash on cycle of 1s (0.5s on and 0.5s off),

when voltage is lower than 3.0V, system is power down.

RSET (Battery internal resistor set)

The internal resistor of the battery can be set by RSET pin, the charging and discharging threshold voltage on

LED will be changed at the same time, accordingly the uniformity of the LED display on the battery level are

adjusted at the same time.

RSET resistor (Kohm)

Battery internal resistance set(mOhm)

>179

93.75

169~179

87.5

159~169

81.25

149~159

75

139~149

68.75

129~139

62.5

119~129

56.25

109~119

50

99~109

43.75

89~99

37.5

79~89

31.25

69~79

25

59~69

18.75

49~59

12.5

39~49

6.25

0~39

0
