No de pièce	PFS7523L/H

Description	PFC Controller with Integrated High-Voltage MOSFET and Qspeed

PDF	37 Pages

Scroll/Zoom	100%

Fabricant	POWERINT [Power Integrations, Inc.]

Site Internet	http://www.powerint.com

Logo

29 / 37 page

Rev. D 04/25

PFS7523-7529/7533-7539

www.power.com

Parameter

Symbol

Conditions

Min

Typ

Max

Units

Qspeed Diode (3A) PFS7523-7529/7533-7535

DC Characteristics

Reverse Current

R = 530 V

J(D) = 25 °C

0.4

J(D) = 100 °C

0.07

Forward Voltage

F = 3 A

J(D) = 25 °C

1.55

J(D) = 100 °C

1.47

Junction Capacitance

R = 10 V, 1 MHz

Dynamic Characteristics (Note: See Figures 19, 20 for dynamic characteristic definition)

Reverse Recovery Time

di/dt = 200 A/µs,

R = 400 V

F = 3 A

J(D) = 25 °C

26.5

J(D) = 100 °C

Reverse Recovery

Charge

di/dt = 200 A/µs,

R = 400 V

F = 3 A

J(D) = 25 °C

40.6

J(D) = 100 °C

65.7

Maximum Reverse

Recovery Current

RRM

di/dt = 200 A/µs,

R = 400 V

F = 3 A

J(D) = 25 °C

2.1

J(D) = 100 °C

3.0

Softness Factor = t

B/tA

di/dt = 200 A/µs,

R = 400 V

F = 3 A

J(D) = 25 °C

J(D) = 100 °C

0.45
