LVTTL OUTPUT SWITCHING CHARACTERISTICS

over recommended operating conditions (unless otherwise noted)

PARAMETER

TEST CONDITIONS

MIN

TYP

MAX

UNIT

tr(RBC)

Clock rise time

0.3

1.5

ns

tf(RBC)

Clock fall time

0.3

1.5

ns

80% to 20% output voltage, C = 5 pF (see Figure 9)

tr

Data rise time

0.3

1.5

ns

tf

Data fall time

0.3

1.5

ns

TBI normal mode (see Figure 3), Rω = 125 MHz, data valid prior

2.5

ns

to RBC0 rising

tsu(d1)

Data setup time (RD0–RD9)

TBI normal mode (see Figure 3), Rω = 61.44 MHz, data valid

5

ns

prior to RBC0 rising

TBI normal mode (see Figure 3), Rω = 125 MHz, data valid after

2

ns

RBC0 rising

th(d1)

Data hold time (RD0–RD9)

TBI normal mode (see Figure 3), Rω = 61.44 MHz, data valid

4

ns

after RBC0 rising

tsu(d3)

Data setup time (RD0–RD9)

TBI half-rate mode, Rω = 125 MHz (see Figure 2)

2.5

ns

th(d3)

Data hold time (RD0–RD9)

TBI half-rate mode, Rω = 125 MHz (see Figure 2)

1.5

ns

TRANSMITTER TIMING REQUIREMENTS

over recommended operating conditions (unless otherwise noted)

PARAMETER

TEST CONDITIONS

MIN

TYP

MAX

UNIT

tsu(d4)

Data setup time (TD0–TD9)

1.6

ns

th(d4)

Data hold time (TD0–TD9)

0.8

ns

tr, tf

TD[0,9] data rise and fall time

See Figure 9

2

ns

Table 3. AVAILABLE OPTIONS

TA

PACKAGE

QFN PLASTIC QUAD FLAT PACK (RHA)

–40°C to 85°C

TLK1221RHA
