AD8372

Rev. 0 | Page 6 of 16

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage, VS

5.5 V

ENB1, ENB2, SDI1, SDI2, SDO1, SDO2,

CLK1, CLK2, LCH1, LCH2

VS + 500 mV

Differential Input Voltage, VIPC1 − VINC1,

VIPC2 − VINC2

V p-p

Internal Power Dissipation

1.4 W

θJA (Exposed Paddle Soldered Down)

34.6°C/W1, 2

θJC (At Exposed Paddle)

3.6°C/W2

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

1 Still air.

2 All values are modeled using a standard 4-layer JEDEC test board with the

pad soldered to the board and thermal vias in the board.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
