7 / 8 page

Figure 8. Tape Dimensions.

Figure 9. Reeling Orientation.

Figure 7a. Recommended reflow soldering profile.

Figure 7b. Recommended Pb-free reflow soldering profile.

Notes:

For detail information on reflow soldering of Avago surface mount LEDs, do refer to Avago Application Note AN 1060 Surface Mounting SMT LED

Indicator Components.

CATHODE SIDE

PRINTED LABEL

USER FEED DIRECTION

20 SEC. MAX.

3 o

C/SEC.

MAX.

120 SEC. MAX.

TIME

183 o

100-150 o

-6 o

C/SEC.

MAX.

60-150 SEC.

3 o

C/SEC. MAX.

240 o

C/ MAX.

217 oC

200 oC

60-120SEC.

3 oC/SEC. MAX.

(Acc. to J-STD-020C)

150 oC

255 - 260 oC

100 SEC. MAX.

10 to 30 SEC.

TIME

6 oC/SEC. MAX.

3 oC/SEC. MAX.

1.50

[0.059]

4.00

[0.157]

4.00

[0.157]

1.75

[0.069]

DIM. C

[SEE TABLE 1]

DIM. A

[SEE TABLE]

DIM. B

[SEE TABLE]

3.50 +/- 0.05

[0.14 +/- 0.002]

8.00 +/- 0.30

[0.315 +/- 0.012]

USER FEED

DIRECTION

COVER TAPE

CARRIER TAPE

0.254 +/- 0.02

[0.01 +/- 0.001]

Diam. 0.60 +/- 0.05
