PL580-35/37/38/39

38MHz-320MHz Low Phase Noise VCXO

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 12/14/06 Page 2

OUTPUT ENABLE LOGICAL LEVELS

Part #

OE

State

0 (Default)

Output enabled

PL580-38 (PECL)

1

Tri-state

0

Tri-state

PL580-35 (PECL)

PL580-37 (CMOS)

PL580-39 (LVDS)

1 (Default)

Output enabled

PIN DESCRIPTIONS

Name

TSSOP

Pin number

3x3mm QFN

Pin number

Type

Description

VDDANA

1

11

P

VDD for analog Circuitry.

XIN

2

12

I

Crystal input pin. (See Crystal Specifications on page 4).

XOUT

3

13

O

Crystal output pin. (See Crystal Specifications on page 4).

SEL2

4

14

I

Output frequency Selector pin.

OE_CTRL

5

15

I

Output enable control pin. (See OE_CTRL Logic Levels).

VCON

6

16

I

Voltage control input.

GNDANA

7

1

P

Ground for analog circuitry.

LP

8

2

-

LM

9

3

-

Tuning inductor connection. The inductor is recommended to be

a high Q small size 0402 or 0603 SMD component, and must be

placed between LP and adjacent LM pin. Place inductor as close

to the IC as possible to minimize parasitic effects and to

maintain inductor Q.

GNDBUF

10

4

P

GND connection for output buffer circuitry.

Q

11

5

O

PECL or LVDS output.

VDDBUF

12

6

P

VDD connection for output buffer circuitry. VDDBUF should be

separately decoupled from other VDDs whenever possible.

QBAR

13

7

O

Complementary PECL, LVDS, Or single ended CMOS output.

GNDBUF

14

8

P

GND connection for output buffer circuitry.

SEL1

15

9

I

Output frequency Selector pin.

SEL0

16

10

I

Output frequency Selector pin.
