DATA SHEET
SE4150L: GPS Receiver IC
Preliminary Datasheet
Skyworks Solutions, Inc.
• Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
202445B • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • July 1, 2019
21
Recommended PCB Footprint – Stencil Apertures Pattern
The stencil apertures design below is only for reference.
It is based on a 6mil [0.15mm] stencil thickness with apertures oversized by 1mil [0.025mm] on the pad metal.
The user should modify the design layout in order to meet their particular solder fillet & solder joint reliability
requirements.
All dimensions in the figure below are in mm.
SE4150L QFN 24-pin [4x4mm] PCB Footprint – Stencil Pattern
Scale 20:1
Units in mm
